CC Control Enclosures

Feautures:
Strong and stable profiled bar with prepared mounting holes (integrated size: 25mm);
Stable structure, exquisite image, spacious inner mounting space, common used accessories;
Three point bolted luxury lock, side panels and back panels are fixed by screws;
Door can be open to 130 degrees, open left or right freely;
All-round Polyurethane Gasket between door and Frame with good sealing performance;
3-sectioned bottom panel, easy to enter cables;
M8 earthling pole mounted on the body, door and the mounting panel;
M8 earthling pole mounted on the body, door and the mounting panel.

Main material:
SPCC cold rolled steel.

Surface finish:
Body of enclosure, frame & doors:
Degreasing, pickling, phosphoric, powder coated, static powered with textured stove enamel RAL7032
Mounting panel ( SPCC cold rolled steel):
Degreasing, pickling, phosphoric, powder coated, static powdered with flat coating RAL2000.

Degree of protection:
Comply with IEC60529, EN60529/10.91 and GB4208-93 standard, IP55

Loading capacity:
Static loading: 800KG


Specification

Model No.

Width
(mm)

Depth
(mm)

Height
(mm)

Packing Dimension
W*D*H

Volume
(CBM)

CC.6418.9■00

600

400

1800

670*470*1830

0.5763

CC.6420.9■00

2000

670*470*2030

0.6392

CC.6422.9■00

2200

670*470*2230

0.7022

CC.8418.9■00

800

400

1800

870*470*1830

0.7483

CC.8420.9■00

2000

870*470*2030

0.8301

CC.8422.9■00

2200

870*470*2230

0.9118

CC.0418.9■00

1000

400

1800

1070*470*1830

0.9203

CC.0420.9■00

2000

1070*470*2030

1.0209

CC.0422.9■00

2200

1070*470*2230

1.1215

CC.2418.9■00

1200

400

1800

1270*470*1830

1.0923

CC.2420.9■00

2000

1270*470*2030

1.2117

CC.2422.9■00

2200

1270*470*2230

1.3311

CC.6518.9■00

600

500

1800

670*570*1830

0.6989

CC.6520.9■00

2000

670*570*2030

0.7753

CC.6522.9■00

2200

670*570*2230

0.8516

CC.8518.9■00

800

500

1800

870*570*1830

0.9075

CC.8520.9■00

2000

870*570*2030

1.0067

CC.8522.9■00

2200

870*570*2230

1.1059

CC.0518.9■00

1000

500

1800

1070*570*1830

1.1161

CC.0520.9■00

2000

1070*570*2030

1.2381

CC.0522.9■00

2200

1070*570*2230

1.3601

CC.2518.9■00

1200

500

1800

1270*570*1830

1.3247

CC.2520.9■00

2000

1270*570*2030

1.4695

CC.2522.9■00

2200

1270*570*2230

1.6143

CC.6618.9■00

600

600

1800

670*670*1830

0.8215

CC.6620.9■00

2000

670*670*2030

0.9113

CC.6622.9■00

2200

670*670*2230

1.0010

CC.8618.9■00

800

600

1800

870*670*1830

1.0667

CC.8620.9■00

2000

870*670*2030

1.1833

CC.8622.9■00

2200

870*670*2230

1.2999

CC.0618.9■00

1000

600

1800

1070*670*1830

1.3119

CC.0620.9■00

2000

1070*670*2030

1.4553

CC.0622.9■00

2200

1070*670*2230

1.5987

CC.2618.9■00

1200

600

1800

1270*670*1830

1.5571

CC.2620.9■00

2000

1270*670*2030

1.7273

CC.2622.9■00

2200

1270*670*2230

1.8975

CC.6818.9■00

600

800

1800

670*870*1830

1.0667

CC.6820.9■00

2000

670*870*2030

1.1833

CC.6822.9■00

2200

670*870*2230

1.2999

CC.8818.9■00

800

800

1800

870*870*1830

1.3851

CC.8820.9■00

2000

870*870*2030

1.5365

CC.8822.9■00

2200

870*870*2230

1.6879

CC.0818.9■00

1000

800

1800

1070*870*1830

1.7035

CC.0820.9■00

2000

1070*870*2030

1.8897

CC.0822.9■00

2200

1070*870*2230

2.0759

CC.2818.9■00

1200

800

1800

1270*870*1830

2.0220

CC.2820.9■00

2000

1270*870*2030

2.2429

CC.2822.9■00

2200

1270*870*2230

2.4639

Definition of Color:

Model No.

Feature of mounting plate

CC.■■■■. ■0■■

Mounting panel: RAL2000, others: RAL7035

CC.■■■■. ■1■■

Mounting panel: Zinc, others: RAL7035

Color

RAL7035

RAL 2000

gray

yallow
